| Usage | Operator system for garage doors in private use |
|---|---|
| Maximum dimensions of up-and-over doors | - Width up to 3500 mm - Weight up to 90 kg |
| Maximum dimensions of sectional doors | - Width up to 5000 mm - Weight up to 90 kg |
| Maximum dimensions of up-and-over doors and canopy doors | - Width up to 3500 mm - Height up to 2250 mm - Weight up to 90 kg |
| Maximum cycles with standard rail 0.8 mm | Up to 16 starts per day |
| Maximum cycles with rail 1.2 mm | Up to 20 starts per day |
| Connection for battery backup | ✔ |
| Output for accessories | ✔ 24V, 250 mA |
| Alimentación | 230 V |
| Absorbed current | 1.1 A |
| Power consumption | 250 W |
| Power consumption in STAND-BY mode | 4 W |
| Push and pull force | 550 N |
| Door travel speed | Maximally 16 cm/s |
| Clase de protección | IP20 |
| Integrated radio receiver | ✔ 868 MHz |
| Integrated lighting | ✔ LED, 1 module with 8 LEDs |
| Dimensions | 190 × 120 × 330 mm |
| Temperatura de funcionamiento | -20°C ÷ +60°C |
| Weight | 6.4 kg |
